Masoneilan SVI2 AP Digital Valve Positioner For Control Valve Supplier From China

1
MOQ
2000USD~4000USD
Precio
Masoneilan SVI2 AP Digital Valve Positioner For Control Valve Supplier From China
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Storage Temperature Limits: -58° F To 185° F (-50° C To 85° C)
Supply Pressure Effect: 0.05% Per Psi Unit
Customized support: OEM, ODM, OBM
Repeatability: ± 0.3% Full Span
Temperature Effect: < 0.005% /° F Typical; -40° F To 180° F (< 0.01% /° C )
Ambient Humidity: 10 To 95% Non-condensing
Conformity/Linearity: ± 0.5% Full Span
Accuracy: ± 0.5%
Información básica
Place of Origin: China
Nombre de la marca: Masoneilan
Model Number: Masoneilan SVI2
Documento: xiangjing valve&instrument ...t .pdf
Pago y Envío Términos
Packaging Details: Based on demand
Delivery Time: 4~8 work week
Payment Terms: T/T
Supply Ability: 50PCS/Month
Descripción de producto
Product Overview

The Masoneilan SVI2 Advanced Performance (AP) Digital Valve Positioner is a high-precision, microprocessor-based instrument designed to provide accurate valve positioning, advanced diagnostics, and seamless communication with process control systems. Built for harsh industrial environments, the SVI2 AP ensures reliability, efficiency, and superior process control in demanding applications.

Features
  • High Accuracy: Exceptional positioning precision for improved process control.
  • Advanced Diagnostics: Real-time valve performance monitoring and predictive maintenance.
  • Flexible Communication: Supports HART® protocol for seamless integration.
  • Robust Design: Resistant to vibration, temperature extremes, and harsh conditions.
  • Easy Setup: User-friendly interface for quick configuration and calibration.
Technical Specifications
Parameter Specification
Model Masoneilan SVI2 Advanced Performance
Control Type Digital valve positioner
Communication Protocol HART®
Input Signal 4-20 mA DC
Supply Pressure 20 to 100 psi (1.4 to 7 bar)
Operating Temperature -40°C to +85°C
Stroke Range Configurable
Enclosure Rating IP66 / NEMA 4X
Material Aluminum or Stainless Steel
Mounting Direct or remote mounting
Certifications ATEX, IECEx, CSA (depending on model)

Applications

The Masoneilan SVI2 AP is ideal for use in:

  • Oil & Gas production and refining
  • Chemical and petrochemical industries
  • Power generation plants
  • Pulp and paper manufacturing
  • Water and wastewater treatment
  • General industrial process control
