Fisher 67C Series Filter Regulator with DVC2000 Digital Valve Controller

1
MOQ
US $1600.00 - 2000.00/ Unit
Precio
Fisher 67C Series Filter Regulator with DVC2000 Digital Valve Controller
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Data Interface: Wired
Diagnostics: Yes
Mounting Type: Integral Mounted
Supply Media: Air, Non Corrosive Gas
Input Signal: Electric
Max Outlet Pressure: 101 psig
Communication Protocol: HART, 4-20mA Analog
Resaltar:

Fisher 67C filter regulator

,

DVC2000 digital valve controller

,

pneumatic control valve with regulator
Información básica
Nombre de la marca: Fisher
Model Number: DVC2000
Documento: xiangjing valve&instrument ...t .pdf
Pago y Envío Términos
Packaging Details: Wooden box + cardboard box + protection
Delivery Time: spot goods
Payment Terms: T/T
Supply Ability: 2000 units per year
Descripción de producto
Fisher 67C Series 67CFR 67DFR Filter Regulator DVC2000 Digital Valve Controller Customized Valve Price
Product Specifications
Attribute Value
Data Interface Wired
Diagnostics Yes
Mounting Type Integral Mounted
Supply Media Air, Non Corrosive Gas
Input Signal Electric
Max Outlet Pressure 101 psig
Communication Protocol HART, 4-20mA Analog
Product Overview

The Fisher 67C Series (67CFR/67DFR) Filter Regulators and DVC2000 Digital Valve Controller form an integrated pneumatic control system designed for precise valve automation. The 67CFR/67DFR regulators ensure clean, stable air supply by combining filtration and pressure adjustment, while the DVC2000 provides adaptive digital control for actuators. Together, they enhance process reliability, reduce maintenance, and optimize energy efficiency in demanding industrial environments.

Technical Parameters
Product Parameter Specification
67CFR/67DFR Regulation Range 0.5-10 bar / 7-145 psi
Flow Capacity 1500 L/min (67CFR) / 3000 L/min (67DFR)
Filtration Rating 5 µm (Standard) / 40 µm (Coarse)
Pressure Port 1/4" NPT / G1/4"
Material Aluminum (Anodized) / Stainless Steel
Protection Class IP65
Operating Temp -20°C to +80°C (-4°F to +176°F)
DVC2000 Input Signal 4-20mA + HART 7
Control Type Pneumatic (Direct/Reverse Action)
Accuracy ±1% Full Scale
Output Pressure 0.2-6 bar / 3-90 psi
Communication HART 7, FOUNDATION Fieldbus (Optional)
Protection Class IP66
Operating Temp -40°C to +85°C (-40°F to +185°F)
Key Features
  • Integrated Pneumatic System: 67CFR/67DFR regulators pair seamlessly with DVC2000 controllers.
  • Dual-Stage Filtration: Removes contaminants and moisture for reliable actuator operation.
  • Adaptive Digital Control: DVC2000's HART 7 protocol enables real-time diagnostics and auto-tuning.
  • Modular Design: Field-replaceable components reduce downtime.
  • Harsh Environment Resistance: IP65/IP66 ratings and wide temperature ranges (-40°C to +85°C).
  • Safety Compliance: SIL-certified for use in hazardous areas.
Applications
  • Oil & Gas: Control valves in pipelines, refineries, and LNG terminals.
  • Chemical Processing: Precise regulation of corrosive or toxic media.
  • Power Generation: Boiler feedwater control and turbine bypass systems.
  • Pharmaceuticals: Sterile environment valve automation.
  • Water Treatment: Pump stations and filtration plant control.
