Rosemount 8705 Magnetic Level Indicator with 1000 Record Storage IP66/67

Rosemount 8705 Magnetic Level Indicator: A Comprehensive Overview

The Rosemount 8705 Magnetic Level Indicator (MLI) is a flagship product within Emerson's extensive portfolio of level measurement solutions. It represents a sophisticated, highly reliable, and versatile system designed for direct, visual level indication in a vast array of industrial processes, particularly those involving hazardous, high-pressure, or high-temperature fluids. As a successor to the renowned 8500 series, the 8705 incorporates advanced engineering and user-centric features to enhance safety, accuracy, and operational efficiency.

Fundamental Operating Principle

At its core, the Rosemount 8705 operates on the proven principle of magnetic coupling and buoyancy, a time-tested method for accurate level detection. The system consists of two primary components: a chamber (also called a float chamber or gauge body) constructed to withstand the process conditions, and an indicator assembly mounted externally.

Inside the chamber, a float—engineered to have a specific density—rides on the surface of the process liquid. Embedded within this float is a powerful, permanent magnet. The indicator assembly features a hermetically sealed, non-magnetic capillary tube containing a series of precisely aligned, magnetically actuated flags or flippers. These flags are bi-color (typically white and a high-visibility red or green) and are mounted on individual pivots.

The magnetic field from the float, transmitted through the chamber wall, couples with the flags in the indicator. As the liquid level and the float move up or down, the magnetic field causes the flags to rotate 180 degrees. The portion of the indicator aligned with the float (and thus the liquid level) displays the colored section, creating a stark, crisp contrast against the white background of the flags above or below. This provides an immediate and unambiguous visual representation of the level within the vessel.

Key Features and Technological Advancements

The 8705 differentiates itself through several critical features:

• Superior Visibility: The indicator flags are larger and designed with vibrant, FDA-compliant colors for excellent long-distance readability, even in low-light conditions. The display is sharp, with no ambiguous "half-flipped" flags.

• Enhanced Safety and Integrity: The system is engineered with safety as a paramount concern. The chamber and indicator are isolated from the process media by a robust pressure boundary. Welded, non-magnetic metal walls ensure zero chance of leakage, making it ideal for toxic, corrosive, or volatile fluids. It carries stringent international certifications like SIL 2/3 (IEC 61508), PED, and CRN, validating its design for critical service.

• Unmatched Versatility: The 8705 is highly configurable. It can be supplied in various materials of construction (e.g., carbon steel, 316SS, Alloy C-276) to handle corrosive applications. It is available in a wide range of pressures (from full vacuum to over 430 bar / 6,250 psi) and temperatures (from -320°F to +800°F / -196°C to +427°C). Options include extended lengths, custom scales, and steam jacketing for fluids that solidify.

• Integrated Options and Flexibility: A significant advantage of the 8705 is its ability to serve as a platform for additional instrumentation. Users can easily integrate Rosemount 8707 Switch Modules for high/low level alarms or pump control and 8700 Series Transmitters (like the 8714) to provide a continuous 4-20 mA analog output signal for remote monitoring and control in a DCS or PLC system. This creates a redundant and highly reliable level measurement system with both local and remote capabilities.

• Reduced Maintenance: The magnetic coupling is a non-contact method, meaning there is no mechanical linkage to wear out. The flags are hermetically sealed within the indicator tube, protecting them from dust, moisture, and corrosion, which ensures a long, maintenance-free service life.

Typical Applications

The Rosemount 8705 is deployed across countless industries, including:

• Oil & Gas: Separators, knock-out drums, fractionation columns, and amine contactors.

• Power Generation: Deaerators, feedwater heaters, and condensate storage tanks.

• Chemical and Petrochemical: Reactors, distillation columns, and storage tanks for aggressive chemicals.

• Pharmaceutical and Food & Beverage: CIP/SIP vessels where hygiene and cleanability are essential.

In summary, the Rosemount 8705 Magnetic Level Indicator is far more than a simple sight glass. It is a robust, safety-certified, and highly adaptable engineered system that provides the most reliable form of direct level measurement. Its ability to offer local visual confirmation while seamlessly integrating with modern control systems makes it an indispensable asset for ensuring process safety, efficiency, and reliability in the most demanding industrial environments worldwide.
